DomCast Metals supplies HDPE adjustment units for raising maintenance holes, catch basins and valve chambers to finished grade. They are also called adjustment rings, riser rings or grade rings. The catalog covers square and round units, sloped units for crowned road surfaces, and thin final-grade shims.
Ontario tender documents usually call these adjustment units rather than rings. Match the wording in your contract documents when you order, and confirm sizes against the structure at quote time. Canadian-owned supplier serving the waterworks market for 80+ years.
Catalogue at a glance
| SKU | Name | Typical use |
|---|---|---|
| LD2424F125 | 24" X 24" Square 1 1/4" | Square flat unit for a catch basin frame, stated thickness. |
| LD2424F150 | 24" X 24" Square 1 1/2" | Square flat unit for a catch basin frame, stated thickness. |
| LD2424F200 | 24" X 24" Square 2" | Square flat unit for a catch basin frame, stated thickness. |
| LD2424F275 | 24" X 24" Square 2 3/4" | Square flat unit for a catch basin frame, stated thickness. |
| LD2424S125 | 24" X 24" 1 1/4" to 2 3/4" 6% Slope | Square sloped unit for a catch basin frame on a crowned road. |
| LD2424S150 | 24" X 24" 3/4" to 1 1/2" | Square sloped unit for a catch basin frame on a crowned road. |
| LD2424S275 | 24" X 24" 2" to 2 3/4" 3% Slope | Square sloped unit for a catch basin frame on a crowned road. |
| LDSP2424FS-025 | Final Grade 24"X24" 1/4" Square | Final grade shim for the last fraction of an inch. |
| LD24R125 | 24" x 1 1/4" Manhole Adjustment Unit | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD24R150 | 24" x 1 1/2" Manhole Adjustment Unit | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD24R200 | 24" x 2" Manhole Adjustment Unit | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD24R400 | 24" x 4" Manhole Adjustment Unit | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD24S150 | 24" x 3/4" to 1 1/2" Manhole Adjustment Unit | Round sloped unit for a maintenance hole frame on a crowned road. |
| LD27R125 | 27" x 1 1/4" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD27R150 | 27" x 1 1/2" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD27R200 | 27" x 2" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD27R400 | 27" x 4" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD27S150 | 27" x 3/4" to 1 1/2" Manhole Adjustment Ring | Round sloped unit for a maintenance hole frame on a crowned road. |
| LD30F150 | 30" x 1 1/2" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD30F225 | 30" x 2 1/4" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD30F400 | 30" x 4" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LD30S225 | 30" x 1 1/2" to 2 1/4" Manhole Adjustment Ring | Round sloped unit for a maintenance hole frame on a crowned road. |
| LD34F200 | 34" x 2" Manhole Adjustment Ring | Round flat unit for a maintenance hole frame of the stated diameter and thickness. |
| LDSP24FS025 | 24" x 1/4" Final Grade Manhole Adjustment Unit | Final grade shim for the last fraction of an inch. |
| LDSP27FS025 | 27" x 1/4" Final Grade Manhole Adjustment Unit | Final grade shim for the last fraction of an inch. |
| LDSP30FS025 | 30" x 1/4" Final Grade Manhole Adjustment Unit | Final grade shim for the last fraction of an inch. |
| BUTYL825 | Butyl Sealant Caulking Large 825ml Tube | Butyl sealant for the joints between stacked units. |
| BUTYL300 | Butyl Sealant Caulking Small 300ml Tube | Butyl sealant for the joints between stacked units. |
Dimensions, weights and compliance with a drawing revision are confirmed per SKU at quote; the catalogue names are the published reference.
Choosing a pattern
LADTECH/DOMCAST speed rings are HDPE adjustment units. They stack between the structure and the cast iron frame to bring the frame to finished grade, in flat or sloped versions, do not absorb water, and install without mortar cure time. OPSS 407 recognizes HDPE and EPS adjustment units (OPSS 1854) alongside precast concrete and rubber units.
- Square units (LD2424F and LD2424S) for catch basin frames, in flat thicknesses and in sloped versions that follow the crown of the road.
- Round units for maintenance hole frames, named by diameter and thickness: LD24R, LD27R, LD30F and LD34F flat units, and LD24S, LD27S and LD30S sloped units.
- Final grade shims (LDSP) for the last fraction of an inch, square or round.
- Butyl sealant (BUTYL825 and BUTYL300) for sealing the joints between stacked units.
Pick the shape and diameter from the frame the unit sits under, the thickness from the height you have to make up, and sloped units where the road is crowned. The OPSD and OPSS castings guide covers how adjustment units and frames are called out in Ontario tenders. Tell us the OPSS 1850 edition or drawing the contract cites; compliance is confirmed per SKU at quote.
How to specify for a quote
Send these with the request:
- Structure. Catch basin, maintenance hole or valve chamber, and the frame it carries.
- Shape and size. Square, or round by frame diameter.
- Height to make up. So we can suggest the stack of thicknesses, including final grade shims.
- Slope. Flat, or the road crown the frame has to follow.
- Quantity per thickness, plus butyl tubes for the joints.
- Standard. The OPSS or municipal clause the units are tendered to, if any.
Use the adjustment unit enquiry form, email sales@domcastmetals.com or call 519 972 3901.
Browse the catalog
Products (28 SKUs)
- 24" X 24" Square 1 1/4" · LD2424F125
- 24" X 24" Square 1 1/2" · LD2424F150
- 24" X 24" Square 2" · LD2424F200
- 24" X 24" Square 2 3/4" · LD2424F275
- 24" X 24" 1 1/4" to 2 3/4" 6% Slope · LD2424S125
- 24" X 24" 3/4" to 1 1/2" · LD2424S150
- 24" X 24" 2" to 2 3/4" 3% Slope · LD2424S275
- Final Grade 24"X24" 1/4" Square · LDSP2424FS-025
- 24" x 1 1/4" Manhole Adjustment Unit · LD24R125
- 24" x 1 1/2" Manhole Adjustment Unit · LD24R150
- 24" x 2" Manhole Adjustment Unit · LD24R200
- 24" x 4" Manhole Adjustment Unit · LD24R400
- 24" x 3/4" to 1 1/2" Manhole Adjustment Unit · LD24S150
- 27" x 1 1/4" Manhole Adjustment Ring · LD27R125
- 27" x 1 1/2" Manhole Adjustment Ring · LD27R150
- 27" x 2" Manhole Adjustment Ring · LD27R200
- 27" x 4" Manhole Adjustment Ring · LD27R400
- 27" x 3/4" to 1 1/2" Manhole Adjustment Ring · LD27S150
- 30" x 1 1/2" Manhole Adjustment Ring · LD30F150
- 30" x 2 1/4" Manhole Adjustment Ring · LD30F225
- 30" x 4" Manhole Adjustment Ring · LD30F400
- 30" x 1 1/2" to 2 1/4" Manhole Adjustment Ring · LD30S225
- 34" x 2" Manhole Adjustment Ring · LD34F200
- 24" x 1/4" Final Grade Manhole Adjustment Unit · LDSP24FS025
- 27" x 1/4" Final Grade Manhole Adjustment Unit · LDSP27FS025
- 30" x 1/4" Final Grade Manhole Adjustment Unit · LDSP30FS025
- Butyl Sealant Caulking Large 825ml Tube · BUTYL825
- Butyl Sealant Caulking Small 300ml Tube · BUTYL300
Common questions
What does Ontario call an adjustment ring?
OPSS terminology is adjustment unit. OPSS 408 lists three material specifications for them: precast concrete units to OPSS 1351, rubber units to OPSS 1853, and high density polyethylene (HDPE) and expanded polystyrene (EPS) units to OPSS 1854. DomCast supplies HDPE units. Source: OPSS.PROV 408, clause 408.05.01.
How many adjustment units are allowed on one structure?
OPSS.PROV 408 states there shall be a minimum of one adjustment unit on the top of the drainage structure, and no more than three are permitted without prior written approval from the Contract Administrator. Always verify against the contract documents governing your project, which may differ from the provincial specification.
What is the difference between an adjustment unit and a lift ring?
OPSS.PROV 408 defines lift rings as circular and rectangular pre-fabricated metal or high density polyethylene units used to adjust the elevation of the grates and covers only, inserted between the frame and the grate or cover. Adjustment units sit under the frame and raise the structure itself.
Do you stock sloped units for crowned roads?
Yes. The catalog includes sloped units alongside flat units. The slope and size are stated in each product name; confirm the required slope against the road cross-section at quote time.
How do HDPE units compare with brick and mortar or precast rings?
OPSS 407 recognizes HDPE and EPS adjustment units (OPSS 1854) alongside precast concrete and rubber units. HDPE speed rings stack to the height you need in flat or sloped versions, do not absorb water, and install without mortar cure time. Seal the joints with butyl.
Do I need butyl sealant?
Yes, the joints between stacked units are sealed with butyl. The catalogue lists a large and a small tube; order enough for every joint in the stack.
Square or round?
Square units go under square catch basin frames; round units go under round maintenance hole and valve chamber frames, matched by diameter. Order by the frame the unit sits under.
What is a final grade shim for?
The thin final grade units make up the last fraction of an inch once the thicker units are stacked, so the frame lands exactly at finished grade.
